Stainless Steel Round Bars
Grevinox Overseas is a prominent domestic manufacturer, supplier, and distributor of high-quality Stainless Steel Round Bars. Conforming to standards such as ASTM A276 and ASTM A479, our SS Round Bars are supplied in bright finish, black finish, peeled, hot rolled, cold drawn, and forged conditions. These bars are highly acclaimed for their superior structural strength, durability, excellent machinability, and high corrosion resistance in extreme environments.
SS Round Bars Specifications
We supply stainless steel round bars in diverse dimensions, finishes, and tolerances matching exact manufacturing applications.
| Parameters | Specifications |
|---|---|
| Standard Specifications | ASTM A276, ASTM A479, ASME SA276 / SA479, DIN 1013, EN 10088-3 |
| Size / Diameter Range | 3 mm to 500 mm (1/8" to 20" diameter) |
| Length Range | 1 meter up to 6 meters, custom cut-to-length orders supported |
| Tolerance Grades | h8, h9, h10, h11, k12, cold drawn and centerless ground tolerances |
| Finishes | Bright Finish (polished/drawn), Black Finish (hot rolled), Peeled, Turned, Centerless Ground |
| Forms Available | Round Bar, Square Bar, Hexagonal Bar, Flat Bar, Wire Rod, Threaded Bar |
| Surface Treatment | Pickled, Sand Blasted, Satin Polish, Mirror Polish |
| Value Added Services | Cutting, Heat Treatment (Annealing, Quenching & Tempering), Machining, Chamfering |
Stainless Steel Bar Grades & Applications
Our comprehensive inventory includes austenitic, martensitic, ferritic, and duplex grades designed to handle high mechanical stress and corrosive exposures.
| Grade Family | Common Grades | Key Features & Applications |
|---|---|---|
| Austenitic (Standard) | SS 304 / 304L, SS 316 / 316L | High tensile strength, superb weldability, and corrosion resistance. Used in pump shafts, fasteners, and chemical processing equipment. |
| Martensitic / Hardenable | SS 410, SS 420, SS 431 | Hardenable by heat treatment. Offers high strength, wear resistance, and moderate corrosion resistance. Used in valves, cutlery, and pump shafts. |
| High Temperature | SS 321, SS 347, SS 310S | Excellent resistance to scaling and oxidation at high temperatures. Used in furnace parts, petrochemical reactors, and aerospace parts. |
| Super Austenitic & Duplex | SS 904L, Duplex 2205, S.Duplex 2507 | Highest resistance to localized pitting and crevice corrosion. Extremely strong. Used in oil & gas equipment, marine hardware, and pulp-bleaching plants. |
Stainless Steel Round Bars Weight Chart
Check the weight calculation chart for Stainless Steel Round Bars (based on formula: \(D^2 \times 0.00623\)) to plan raw material dispatch weights.
| Diameter Size (mm) | Weight (kg per meter) | Diameter Size (mm) | Weight (kg per meter) | Diameter Size (mm) | Weight (kg per meter) |
|---|---|---|---|---|---|
| 5 mm | 0.15 kg/m | 20 mm | 2.47 kg/m | 60 mm | 22.20 kg/m |
| 6 mm | 0.22 kg/m | 22 mm | 2.98 kg/m | 70 mm | 30.22 kg/m |
| 8 mm | 0.39 kg/m | 25 mm | 3.86 kg/m | 80 mm | 39.46 kg/m |
| 10 mm | 0.62 kg/m | 28 mm | 4.83 kg/m | 90 mm | 49.94 kg/m |
| 12 mm | 0.89 kg/m | 32 mm | 6.31 kg/m | 100 mm | 61.65 kg/m |
| 14 mm | 1.21 kg/m | 36 mm | 7.99 kg/m | 120 mm | 88.78 kg/m |
| 16 mm | 1.58 kg/m | 40 mm | 9.87 kg/m | 150 mm | 138.72 kg/m |
| 18 mm | 1.99 kg/m | 50 mm | 15.42 kg/m | 200 mm | 246.60 kg/m |
Quality Assurance & Testing
Every batch of stainless steel round bars undergoes stringent metallurgical tests to assure compliance with mechanical and dimensional standards before supply. Mill Test Certificates (MTC) conforming to EN 10204 3.1 are provided.
- Ultrasonic Testing (UT): NDT testing to identify any internal defects, voids, or micro-cracks inside forged/rolled bars.
- Chemical Composition PMI: Positive Material Identification to verify exact nickel, chromium, and molybdenum percentages.
- Mechanical Properties Test: Verification of Yield Strength, Tensile Strength, Elongation, and Brinell/Rockwell Hardness.
- Dimensional Precision Check: Tolerance verification (using micrometers) to guarantee alignment with target tolerances (e.g. h9/h11).
- Macro & Micro Structure Test: Evaluates grain boundaries and cleanliness of the steel.
- Third-Party Inspection (TPI): Support for external inspections by agencies like SGS, TUV, DNV, Lloyds, and BV.
Industrial Applications
Our stainless steel round bars provide exceptional strength and precision machining performance. Key industries served include:
- Machined Components & Fasteners: Manufacturing of shafts, pins, bolts, studs, valves, and gear parts.
- Marine Hardwares: Propeller shafts, rudder stocks, and fittings exposed to saltwater.
- Oil & Gas: Downhole drilling components, valve bodies, and refinery equipment.
- Automotive & Transport: Drive shafts, pistons, axle components, and structural pins.
- Medical Equipment: Surgical tools, orthopedic implants, and precision laboratory parts.
- Pumps & Electric Motors: High-precision pump shafts and rotor components.
Domestic Supply Network & Cities Served
Grevinox Overseas is a trusted domestic supplier and distributor of high-quality Stainless Steel Round Bars across India. We deliver top-grade piping materials to all major industrial zones, manufacturing hubs, and cities including:
West & South India
- Mumbai, Pune, Nagpur (MH)
- Thane, Nashik, Aurangabad (MH)
- Ahmedabad, Surat, Vadodara (GJ)
- Rajkot, Jamnagar, Vapi (GJ)
- Bengaluru, Mangaluru, Mysuru (KA)
- Chennai, Coimbatore, Madurai (TN)
- Hyderabad, Warangal (TS)
- Visakhapatnam, Vijayawada (AP)
- Kochi, Kozhikode (KL)
- Vasco da Gama, Panaji (GA)
North, East & Central India
- New Delhi, Noida, Gurugram
- Ghaziabad, Faridabad, Sonipat
- Ludhiana, Jalandhar, Amritsar (PB)
- Kanpur, Lucknow, Agra (UP)
- Indore, Bhopal, Jabalpur (MP)
- Raipur, Bhilai, Bilaspur (CG)
- Kolkata, Howrah, Durgapur (WB)
- Jamshedpur, Ranchi, Dhanbad (JH)
- Bhubaneswar, Cuttack, Rourkela (OD)
- Guwahati, Dibrugarh (AS)
Prompt Delivery & Supply Chain
We partner with leading transport and cargo services in India to ensure prompt dispatch, safe transit, and timely delivery of your orders directly to your factory, warehouse, or project site with proper documentation (MTC, GST Invoice, Lorry Receipt).
